CNC Router FS1325A

Get a Price/Quote

CNC Router FS1325A Specification

Product Type
CNC Router

General Use
Woodworking, MDF, Acrylic, PVC, Aluminum, Soft Metals

Material
Steel, Aluminum, ABS Plastic, MDF, PVC

Type
Automatic CNC Router

Capacity
High Production

Weight (kg)
1300 kg

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Bar Feeder
No

Power Source
Electric

Power Consumption
3.5 kW

Rigidity
High

Voltage
380 V / 220 V

Motor
Stepper Motor

Table Size
1300 x 2500 mm

Spindle Speed
0-24000 rpm

Axial Choice
XYZ

Dimension (L*W*H)
3200 x 2200 x 1600 mm

Feature
Automatic Tool Changing, High Precision, Durable Structure

Color
Blue and White

Max Travelling Speed
25 m/min

Travelling Positioning Accuracy
±0.05 mm

Working Voltage
AC380V/50Hz

Spindle Motor Power
3.5 kW (Water-cooled)

Max Working Speed
15 m/min

Interface
USB / Parallel Port

Command Code
G Code

Drive System
Rack and Pinion for X/Y, Ball Screw for Z

Supported Software
ArtCAM, Ucancam, Type3, Wentai

Working Area
1300 x 2500 x 200 mm

Repeating Positioning Accuracy
±0.05 mm

Control System
DSP / NC Studio / Mach3

About CNC Router FS1325A

Specification

Item	FS1325A	FS1530A	FS2138A
Travelling area	25001260200/300mm	31001570200/300mm	38002100200/300mm
Working area	24801230180/280mm	30801550180/280mm	37802050180/280mm
Table size	2500*1230mm	3100*1560mm	3800*2050mm
Transmission	X/Y rack and pinion drive, Z ball screw drive
Table structure	T-slot vacuum / T-slot
Spindle power	3.0 / 4.5 / 6.0KW
Spindle speed	18000r/min
Travelling speed	25m/min
Working speed	15m/min
Driving system	Stepper / Yaskawa
Voltage	AC380/3PH/50HZ
Controller	NC ARM hand-held controller / NC-Studio / DSP

High Precision and Rugged Durability

Benefit from remarkable repeatability0.05 mmensured by the machines advanced mechanics, sturdy steel frame, and high-grade components. Its durability and automatic tool-changing capability make it ideal for sustained high-production runs, reducing downtime and boosting efficiency in demanding workshops.

Seamless Compatibility and Control

With support for popular CAD/CAM software like ArtCAM and Ucancam, and a choice of DSP, NC Studio, or Mach3 controllers, the FS1325A integrates effortlessly into modern production environments. Its user-friendly control options and USB/Parallel interface allow flexible, straightforward operation for both new and experienced CNC operators.

Versatile Material Processing

The FS1325A CNC Router is designed for versatility, capable of machining wood, MDF, acrylic, PVC, aluminum, and soft metals. Whether producing intricate signage, detailed cabinetry, or precision metal parts, the machine adapts easily, making it a reliable asset across diverse manufacturing sectors.

FAQs of CNC Router FS1325A:

Q: How does the automatic tool changing feature benefit production efficiency?

A: The automatic tool changing system reduces operational downtime by allowing the machine to switch tools during a job without manual intervention. This streamlines the workflow, increases throughput, and ensures consistent precision across multistep processes.

Q: What types of materials are supported by the FS1325A CNC Router?

A: This CNC router is suitable for a range of materials including wood, MDF, acrylic, PVC, aluminum, soft metals, steel, and ABS plastic. Its high rigidity and powerful spindle make it adept for both soft and harder material processing.

Q: When should I use the rack and pinion drive versus the ball screw mechanism?

A: In the FS1325A, the rack and pinion system is used for X and Y axes to enable fast, smooth movements over large distances, ideal for big workpieces. The Z axis uses a ball screw drive for fine, high-precision vertical adjustments during intricate engraving or cutting.

Q: Where can the FS1325A be installed and what are the requirements?

A: The CNC router is suitable for workshops, industrial design studios, and manufacturing facilities. Ensure an appropriate AC380V/50Hz (or 220V) power supply, and sufficient space for its dimensions (3200 x 2200 x 1600 mm) for safe operation and maintenance access.

Q: What is the process for programming and starting a machining job with this router?

A: Prepare your design using supported CAD/CAM software (e.g., ArtCAM or Ucancam), then export the G Code to the control system (DSP, NC Studio, or Mach3) via USB or parallel port. Set the workpiece, calibrate the machine, and commence the programmed operation.

Q: How does the high positioning accuracy impact finished product quality?

A: The 0.05 mm repeatability ensures every cut or engraving is reliably precise, leading to superior surface finishes and exact parts replicationespecially essential for intricate patterns, joinery, and components that require tight tolerances.

Q: What are the main benefits of using a stepper motor in this CNC router?

A: Stepper motors deliver reliable motion control, allowing precise positioning and repeatability. They minimize mechanical complexity and maintenance, contributing to the overall high durability and stable operation of the FS1325A in continuous production environments.
