ASE SERIES ULTRA LARGE FORMAT FIBER LASER CUTTING MACHINE

Get a Price/Quote

ASE SERIES ULTRA LARGE FORMAT FIBER LASER CUTTING MACHINE Specification

Working Area
3 m x 12 m and above

Power
6000-30000W (varies by model)

Technology
High Performance Fiber Laser

Phase
3 Phase

Usage & Applications
Industrial Metal Sheet and Plate Cutting, Shipbuilding, Machinery, Construction, Large-Scale Fabrication

Product Type
Ultra Large Format Fiber Laser Cutting Machine

Laser Type
Fiber Laser

Material
Stainless Steel, Carbon Steel, Aluminum, Brass, Copper, Galvanized Sheet, Titanium, Alloys

Cutting Thickness
up to 40 mm (material dependent)

Cutting Area
3000 mm x 12000 mm (other sizes available)

Cutting Speed
max 110 m/min (material dependent)

CNC Or Not
Yes

Computerized
Yes

Automatic Grade
Automatic

Cooling Mode
Water Cooling

Control Software
CypCut / FSCUT / HypCut

Graphic Format Supported
AI, DXF, PLT, BMP, DST, DXP

Control System
CNC Control

Voltage
380V / 50Hz, 3 Phase

Weight (kg)
18000-30000 kg (varies by model)

Dimension (L*W*H)
16100 x 3950 x 2250 mm (typical)

Capacity
Customizable

Feature
High Power, Ultra Large Working Area, High Precision, Low Maintenance

Color
Custom/Standard Factory Color

Remote Control
Wireless Control Pendant (optional)

Max Acceleration
1.5 G

Lubrication System
Automatic Central Lubrication

Table Structure
Heavy Duty Welded Bed

After Sales Support
Spare Parts, Online and Onsite Technical Support

Software Updates
Free within Warranty

Monitoring System
CCD Camera Monitoring (optional)

Transmission Method
Double Drive Gantry Structure

Drive System
High Precision Rack & Pinion + Servo Motors

Dust Collection
Advanced Smoke & Dust Extraction System

Installation Service
On-site Setup and Training Provided

Laser Source Brand
Raycus/IPG/MAX/Precitec (optional)

Positioning Accuracy
±0.03 mm

Auxiliary Gas
Oxygen, Nitrogen, Air (user selectable)

Maximum Sheet Weight Capacity
Up to 8 tons (depending on specific model)

Safety System
Full Enclosure & Protection System (optional)

Repeatability Accuracy
±0.02 mm

Operating Temperature Range
5°C - 40°C

About ASE SERIES ULTRA LARGE FORMAT FIBER LASER CUTTING MACHINE

Introducing the ASE SERIES Ultra Large Format Fiber Laser Cutting Machine - the superb choice for industrial metal cutting. Experience world-class precision with positioning accuracy of 0.03 mm and repeatability of 0.02 mm. Equipped with high power Raycus/IPG/MAX/Precitec lasers (up to 30000W), double drive gantry, and preeminent heavy-duty bed. Exclusive promotion for traders, distributors, and suppliers in India - Order Today to secure outstanding after-sales support, installation service, and free software updates within warranty. Customizable capacity and cutting area up to 14000mm x 2500mm.

Optimal Usage Across Industries

The ASE SERIES Ultra Large Format Fiber Laser Cutting Machine excels in robust industrial sectors, including shipbuilding, construction, machinery, and large-scale fabrication. Its versatile usage caters to general and specific applications such as cutting stainless steel, carbon steel, aluminum, brass, copper, galvanized sheet, titanium, and alloys. This machine is designed for heavy-duty, continuous operations, ensuring reliable performance and precision, making it indispensable for both custom manufacturing and high-volume production environments.

Efficient Supply & Order Fulfilment

With significant supply ability and streamlined order processing, the ASE SERIES ensures rapid market entry and high market value for buyers. Packaging is handled meticulously for robust protection during transport. Sample machines are available for assessment prior to purchase, facilitating confident order completion. Dedicated support from order to delivery guarantees a hassle-free experience, whether you require a single unit or a bulk consignment.

Specification

Machine model	14025 ASE
Working Area	14000mm*2500mm (Other formats can be customized)
Laser Power	12000W/8000W/6000W
X/Y axis positioning accuracy	+/-0.03mm
X/Y axis repeat positioning accuracy	+/-0.02mm
Power rated voltage and frequency	380V 50Hz/60Hz

FAQ's of ASE SERIES ULTRA LARGE FORMAT FIBER LASER CUTTING MACHINE:

Q: How does the ASE SERIES ensure precise metal cutting?

A: The ASE SERIES utilizes high precision rack and pinion drive systems, servo motors, and CNC control, delivering exceptional positioning accuracy of 0.03 mm and repeatability of 0.02 mm, crucial for consistent, flawless results.

Q: What is the process for ordering and receiving the machine?

A: Orders are processed efficiently with full support, including comprehensive packaging for safe transport. On-site installation and training are provided, ensuring that the machine is operational and your team is ready for production.

Q: When are samples available for evaluation?

A: Sample machines are available on request, allowing buyers to evaluate performance and suitability before committing to a full purchase or larger order.

Q: Where can the ASE SERIES be used effectively?

A: This machine is ideal for use in shipyards, construction, machinery manufacturing plants, and any industrial setup requiring ultra-large format sheet and plate cutting capabilities.

Q: What are the benefits of choosing the ASE SERIES for industrial fabrication?

A: Key benefits include world-class cutting speed (up to 110 m/min), heavy-duty construction, automatic lubrication, advanced dust extraction, wireless remote control, and optional full enclosure safety systems, ensuring superior productivity and operator safety.
